The Structure Laboratory includes some of the most modern equipment for testing materials and structures.
Some of the larger equipment located in EB077G:
500T Structural Testing System
Features and application:
Multi-channel loading system. It can be used to apply
load from 2 directions for statistic test, with 5000kN
capacity, 4 m high space for specimens. Also, it can
be used to apply dynamic load from 4 directions with
capacity 500 kN, and 2 m * 3 m space for testing the
sample.
200T Structural Testing System
Features and application:
This machine is used for compressing test for large specimen with the testing space of 1.2 m * 3 m.
Concrete Mixer
Features and application:
The capacity of concrete mixer is 350 L. It is used for making large amount of concrete and casting.
Vibration Table
Features and application:
Customized large vibration table, which is used to remove the internal cavity of freshly casted concrete
samples and vibrate them evenly.
Compressing Machine
Features and application:
Compressing machine for testing compressive strength for concrete cubes and cylinders.
50T Triaxial Tester
Features and application:
This machine is an electro-hydraulic servo control
multi testing system, which can be used for triaxial
test loading from vertical Z direction, horizontal X
and horizontal Y direction.
Universal Testing Machine
Features and application:
This is a 300 kN load electronic universal testing machine. The application is for tensile, compressive, and bending tests of materials or structures.
Some of the smaller equipment located in EB077B:
Autoclave machine
Features and Applications:
Steam heating and pressure equipment. It is used for heating and pressure curing of concrete materials.
Freeze-thaw Machine
Features and Applications:
Used for low-temperature rapid freeze-thaw testing and curing of concrete materials.
Concrete Mortar Mixer
Features and Applications:
This is a 5 L mortar mixer. It is used for mixing mortar and casting.
Concrete Mortar Mixer
Features and Applications:
This is a 30 L concrete mixer. It is used for making small amount of concrete and casting.
Concrete Mortar Mixer
Features and Applications:
This is a 5 L mortar mixer. It is used for mixing a small amount of mortar and casting.
Concrete Mortar Mixer
Features and Applications:
This is a 2.5 L mortar mixer. It is used for mixing a small amount of mortar and casting.
Concrete Carbonation Test Chamber
Features and Applications:
This is a concrete aging test equipment. It is used for constant temperature, humidity, and high concentration carbon dioxide curing of concrete specimens.
Double End Grinding Machine
Features and Applications:
It is used for smoothing the end face of concrete specimens.
